Name: | Auto Beer Filling Machine Beverage Bottle filling capping equipment |
Driven Type: | Electric |
Material: | Stainless Steel |
Processing Types: | Automatic Bottle Filling Sealing Machine |
Usage: | Beverage Packaging |
Warranty: | One Year |
Name: | Auto Beer Filling Machine Beverage Bottle filling capping equipment |
Application
The machine is widely used in the food, cosmetic, pharmaceutical, oil, water and other industries
The machine is specialized in filling all high and low viscosity materials, such as shampoo, lotion, paste, peanut butter, honey, oil, juice, water etc.
Description:
This Beer Filling Machine Wash-filling-capping 3-in-1unit is used to produce stainless steel bottled beer. The BGF Wash-filling-capping 3-in-1unit:beer Machinery can finish all the process such as washing, filling and sealing, it can reduce the materials and Outsiders touch time, improve the sanitary conditions, production capacity and economic efficiency.
Feature;
1. Using the conveyor sent access and move wheel in the bottle directly connected technology; canceled screw and conveyor chains, this enable the change the bottle-shaped become easier.
2. Bottles transmission adopt clip bottle neck technology, bottle-shaped transform not need to adjust the equipment level, only change related the curved plate, wheel and nylon parts is enough.
3. The specially designed stainless steel bottle washing machine clip is solid and durable, no touch with the screw location of bottle mouth to avoid secondary pollution.
4. High-speed balanced pressure flow valve filling valve, filling fast, filling accurate and no liquid spit out.
5. Spiraling decline when output bottle, transform bottle shape no need to adjust the height of conveyor chains.
6. Host adopt advanced PLC automatic control technology, the key electrical components from famous company such as Japan's Mitsubishi, France Schneider, OMRON or ABB
specification
Model |
Capacity |
Motor power (kw) |
Dimension (L*W*H) |
BGF6-6-1 |
400-600 |
2kw |
1600*1200*2200 |
BGF14-12-4 |
1200-1800 |
2.2kw |
2000*1800*2200 |
BGF18-18-6 |
3000-4000 |
3.7kw |
2460*1720*2650 |
BGF24-24-8 |
5000-6000 |
5.5kw |
3100*2100*2650 |
BGF32-32-10 |
7000-8000 |
6.5kw |
3500*2500*2650 |
BGF40-40-12 |
8000-9000 |
7.5kw |
4600*3300*2650 |
BGF50-50-12 |
13000-15000 |
11kw |
5300*4500*3400 |
BGF60-60-15 |
18000-20000 |
15kw |
6500*4500*3400 |
