Name: | Shanghai supplier automatic essential oil filling machine,120ml bottling Vegetable Oil / Food Oil Filling Machine |
Driven Type: | Electric |
Material: | Stainless Steel |
Processing: | Bottle Packing Machine |
Name: | Shanghai supplier automatic essential oil filling machine,120ml bottling Vegetable Oil / Food Oil Filling Machine |
Model HG-SF500-6
Filing head number 6
Capacity 500-1500 bottles/hour
Filling accuracy ≤ ±1%
Pass rate ≥ 98%
Power supply AC220V, 50/60Hz
Bottle material PET plastic glass bottle
capping station 2
Appllication:
Automatic bottled rotary edible oil filling machine/equipment is suitable for bottling/filling vegetable oil, peanut oil, sunflower oil, soybean oil, rap oil and so on cooking oil into bottles or containers.
The vegetable oil bottling line has totally closed form. When filling, it has high accuracy. It is compact and perfect. Liquid cylinder and conduits can be easily disassemble and clean. It is also suitable for containers of all figures. The machine uses high-quality stainless steel frames and international famous brand electrical components. It applies to GMP standard requirements.
Feature:
1. This machine has convenient and swift measurement, good shape and compact structure.
2. The places contacting with the materials are made of high-quality stainless steel (usually using SUS 304, the Medical SUS 316).
3. High speed filling valve, guarantees liquid has precise level and no waste is incurred
4. The oil filling machine is automatic controlled by computer (PLC ) and touch screen control panels.
5. The control system has the function of control producing speed, bottle block auto stop and production counting
Specification:
Capacity |
5000BPH 500ml |
Bottle standard |
200-2000ml with same bottle diameter |
Bottle washing position |
18 |
Bottle filling position |
18 |
Bottle capping position |
6 |
Bottle washing consumption |
1000kg/h |
Water pressure of bottle washing |
0.18-0.25Mpa |
Gas source pressure |
0.4Mpa |
Filling pressure |
0.4Mpa |
Filing precision |
+5MM |
Material |
Stainless Steel SUS304 |
Autoamtic control systerm |
PLC touch screen |
Gas consumption(m/min) |
0.8 |
Total power |
7.5kw |
Weight |
5500kg |
Size |
3950*3150*2450MM |
