| Name: | Supply of starch packaging machine - powder quantitative packaging machine - automatic powder filling machine |
| Driven Type: | Electric |
| Material: | Stainless Steel |
| Processing: | Bottle Packing Machine |
| Name: | Supply of starch packaging machine - powder quantitative packaging machine - automatic powder filling machine |
Decscription:
Powder Quantitative Packaging Machine.The material contact parts hopper, measuring spiral, stirring, etc. are made of stainless steel; use of high stability, high precision weighing sensor, weighing module; interface is simple, intuitive display; independent packaging weight input, weighing weight Display window, the display window with high-brightness LED display; menu operation is simple, intuitive and friendly; manual assistance on the bag (or barrel), pneumatic folder bag; weighing system independent Weighing, weighing accuracy, high speed, load cell Adopting TOLEDO load cell; asynchronous motor control screw feeding, frequency converter speed regulation, big and small double helix speed measurement and feeding, high control accuracy. Equipment Model: YSDF-B type
Technical Parameters
Power supply: AC380V 900W
Packaging accuracy: ± 1%
Packaging specifications: 5g-5000g (need to replace the filling parts)
Packaging speed: 1500-2500 bags / hour (depending on packaging specifications and materials)
Total weight: 280kg
Machine size: 1000 × 850 × 1850mm
SPECIFICATIONS |
||||
Technical Parameters |
Model |
HJ-25JL-B |
HJ-50JL-B |
|
Hopper |
25L |
50L |
||
Packing weight |
1-500g |
10-5000g |
||
Packing accurate |
±1-5g |
±1-10g |
||
Filling speed |
40-120 times/minute |
40-120 times/minute |
||
Power supply |
3P AC208-415V 50/60Hz |
|||
Total power |
0.93KW |
1.4KW |
||
Total weight |
130kg |
260kg |
||
Overall dimensions |
800*790*1900mm |
1140*970*2200mm |
||
Advantages |
1.Full stainless steel structure, combined transparent hopper, can be easily cleaned without any tool. 2. Servo motor and servo drive controls the auger. 3. Designs of tracking type weighing feedback proportion, overcome the packing weight changes due to different bulk specific weight material. 4. The parameters of different products can be saved , stored up to 10 kinds of products. |
|||
