| Name: | Automatic 5 litre oil filling machine with piston and weighing bottle filling |
| Driven Type: | Electric |
| Material: | Stainless Steel |
| Processing: | Bottle Packing Machine |
| Name: | Automatic 5 litre oil filling machine with piston and weighing bottle filling |
Name HG-ZLDG-8 oil filling machine
Filling speed 800-2200 bph
filling heads 2-8 piece
Filling precision ±0.5
Gas consuption 0.15
Pressure 0.5-0.8
Capacity 100-5000ml
Description:
The production line make of liquid oil filling machine, sealing machine and conveyor system, it mainly use to fill oil to plastic bottles (barrels) glass bottles and seal the bottle, such as edible oil, lubricants, various washing liquid, oil and chemical products. It also can be used to fill and seal beverage, such as mineral water, pure water, as well as various non-gas beverages. It has advanced structure, smooth, easy to operate and maintain suitable for the different bottles, which is consistent with the hygiene requirements, it is a good choice for small plant.ZLDG Automatic liquid oil filling machine
Feature:
All the parts touch with raw materials adopt high quality stainless steel;
Figure show the filling capacity
PLC microcomputer program control;
Dual-speed filling control technology;
Computer control quantity, linear filling;
Anti-dropper filling valve
Specification:
Model |
ZLDG-2 |
ZLDG-4 |
ZLDG-6 |
ZLDG-8 |
Throughput(b/h) |
200-600 |
400-800 |
600-1200 |
800-2200 |
Filling heads |
2 |
4 |
6 |
8 |
Capacity(L) |
50-5000ml |
50-5000ml |
50-5000ml |
50-5000ml |
Filling precision(%) |
±≤0.5 |
±≤0.55 |
±≤0.6 |
±≤0.65 |
Power(kw) |
1.1 |
1.6 |
2.5 |
3.1 |
Dimension(mm) |
800x650x1700 |
1200x650x1700 |
1600x650x1700 |
2100x650x1700 |
Weight(kg) |
300 |
400 |
600 |
800 |
