Name: | 200ml-500ml electronic smoke,eye drop liquid essential oil filling, capping and labeling machine line with Piston pump |
Driven Type: | Electric |
Material: | Stainless Steel |
Processing: | Bottle Packing Machine |
Name: | 200ml-500ml electronic smoke,eye drop liquid essential oil filling, capping and labeling machine line with Piston pump |
Name HG-ZLDG-4
Capacity 50-70 bph
Volume 50-500ml
Capping rate ≥98%(adjusted according to the cap feature)
Speed control frequency speed adjustment
Power supply single phase, 220V 50Hz
Pump Mechanical Piston pump
Description:
This machine is applied for 200ml-500ml round plastic bottle or glass bottle Electronic smoke, essential oil, eye drop liquid filling etc. in plastic or glass bottles. There is high accuracy cam mechanism to provide Graduated dial to locate the cap on, accelerating cam transmission capping head lifting.
Feature:
1.constant torsion capping, mechanical pump dosing and filling; touch screen control, no bottle no filling, no inside and outside cap, with advantage of stable transmission, accurate location, accurate dosing, convenient operation etc.
2.This filling system is widely used in food, chemical, beverage industries etc., suitable for small bottle filling and capping, made in SUS304 stainless steel and SUS316 anti-corrosion stainless steel for the part in contact with material, which is complied with GMP standard.
3. To meet the labeling speed and labeling accuracy, normal round bottle labeling machine can not meet the requirement, need rotary disc labeling machine (for higher capacity) with 3 fix points labeling (for accuracy labeling)
Specification:
Applied Product |
Electronic smoke, essential oil, eye drop liquid |
Capacity |
50-70 bpm |
Filling heads |
4 heads |
Filling range |
20ml-500ml |
Filling accuracy |
10-20ml |
Filling accuracy |
±1%~3% |
Capping head |
2 |
Capping rate |
≥98%(adjusted according to the cap feature) |
Speed control |
frequency speed adjustment |
Labeling speed |
0-70pcs/min(depends on bottle) |
Labeling head |
6 |
Power supply |
single phase, 220V 50Hz |
Size(L*W*H) |
about 2500mm X 1300mm X 1800mm |
