Name: | water pouch packing machine manufacturers automatic drinking mineral water filling machine 4000bph |
Driven Type: | Electric |
Material: | Stainless Steel |
Processing: | Bottle Packing Machine |
Name: | water pouch packing machine manufacturers automatic drinking mineral water filling machine 4000bph |
Feature
1.Man-machine interface control, easy to operate
2.Automatic billet, the billet, take the bottle, row bottles
3.Mold change quickly
4.High degree of automation to reduce bottle contamination
5.Equipment performance is stable and reliable
6.Easy to maintain
Description
Air delivery machine
Rinsing machine
Filling machine
Capping machine
Technical Parameters
Model(CGF) |
14-12-4 |
18-18-6 |
24-24-8 |
32-32-10 |
40-40-12 |
50-50-15 |
60-60-15 |
70-70-18 |
80-80-18 |
Rinsing heads |
14 |
18 |
24 |
32 |
40 |
50 |
60 |
70 |
80 |
Filling heads |
12 |
18 |
23 |
32 |
40 |
50 |
60 |
70 |
80 |
Capping heads |
4 |
6 |
8 |
10 |
12 |
15 |
15 |
18 |
18 |
Capacity(BPH) |
4000 |
6000 |
10000 |
12000 |
18000 |
22000 |
25000 |
28000 |
35000 |
Motor power(KW) |
2.2 |
3.5 |
4.5 |
6.0 |
7.5 |
9.5 |
11.2 |
15.0 |
18.0 |
Dimensions |
2100*1500*2200 |
2300*1700*2400 |
2800*2200*2400 |
2900*2200*2500 |
3600*2700*2850 |
5300*3200*2850 |
5600*4500*2850 |
6000*4800*2850 |
6500*5000*2850 |
Weight (KG) |
2000 |
