Non-food area components are increasingly tight

In non-food areas, pneumatic technology is mainly used for bagging, packaging, labeling, testing and capping devices, although the region of the pneumatic components do not need to contact the production of raw materials, but usually still need to have standardized, easy to clean, intelligent environmental And compact structure and so on.As the current food packaging equipment requires more functionality in a limited space, the size requirements for pneumatic components are becoming more stringent.Typical products include the UK NORGREN easy to clean valve island VM series, the width of only 10MM of the valve body can provide 430L / MIN flow, can be 2 to 20-bit integration, and in line with IP65 and food packaging in the complex control of the trend.In addition, the advanced food packaging equipment commonly used by the filter, pressure relief valve and oil lubrication valve and cylinder composed of non-oil lubrication pneumatic system,This system requires pre-sealing of the grease at the component, without oil mist, for long periods of time without the need for additional grease, reducing fuel consumption and costs, improving the environment, providing easy maintenance and stable performance.

Pneumatic device intelligent

With the increasing process of food processing, food packaging automation level is also rising, the current food packing machine research and development is moving in the high-speed, multi-functional and intelligent control of the direction of development, industrial robots, microelectronics, computers, intelligent And image sensing technology will be more and more widely used, and applied to food packaging machinery pneumatic technology, intelligent and network will become inevitable.

Intelligent cylinder is a master of the cylinder of intelligent, NORGREN company's intelligent cylinder, for example, this cylinder built-in solenoid valve and speed control valve, the cylinder provides FIELDBUS and ASI interface, can achieve remote control of the bus. It has IP66 degree of protection, easy to flush; but also in line with ISO / VDMA standards, and ordinary standard cylinder can be interchangeable. The use of the cylinder can replace the traditional entire pneumatic circuit.

Intelligent pneumatic triple connection makes the air treatment system self-diagnosis possible, most of the pneumatic system failure due to air treatment system, intelligent triple pieces to effectively solve this problem. Which can continuously monitor the pneumatic system and at any time through the FIELDBUS and ASI connection display the relevant data, informing when the need to replace the filter or oil, the pressure state is normal, and record the use of time, so that the failure rate to a minimum, Cost, improve uptime and production capacity.

Intelligent and networked pneumatic technology development and application of food packaging machinery will further intelligent, to achieve self-diagnosis equipment, thereby enhancing the domestic food packaging machinery automation level.
